Comments Off on 6″ Traction Engine Part 1 I started building the 6″ scale version of the Little Samson traction engine shortly after finishing the 3″ one. I liked it so much that i felt it would be really nice to have an identical pair of engines, albeit in different sizes: quarter scale and half scale. I started to home in on the 3' Little Samson model, the casting being available from Edward George, whose book 'Scale Model Traction Engine Design and Construction' I had brought and read cover to cover, (and still is used very very regularly). I even brought the drawings to see if there was anything that I thought 'that's beyond me'.

Little

I'll start at the end with this engine. It came in three weeks ago and I'm really smitten by it - beautifully made, fit and finish is excellent throughout, the paintwork shows just what can be achieved with nothing more than a top quality brush and it runs like a sewing machine.

Steel boiler by Bell Boilers of Gloucester, steel tubes expanded in, 125psi working pressure, feed by injector and crankshaft pump. Twin safety valves, which uniquely in this design exhaust into the chimney, a very civilised arrangement - you barely hear them lift.

The boiler was delivered at the end of 2009, the engine was completed in 2010 and first registered for the road in that year. It has been steamed seven times in total and remains in as-new condition throughout. The work of a talented engineer, who warmed up for this project by building the same engine in 3 inch scale - his log of the build of this one has subsequently been published as a book, which I would recommend whether or not you are planning to build a 'Little Samson', it contains a great deal of information useful to building any type of traction engine in a home workshop.

Complete with a set of drawings and double tender-mounted seat, there's a clip of it running outside the workshop here.

Length 7 ft
Width 35 inches
Height 55 inches

3D Models of the Little Samson Traction Engine

This WEB site contains 3D drawings of the Little Samson Traction Engine.
The drawings were created using the Personal Edition of Alibre Design.
Details of the Little Samson Traction Engine can be found at www.littlesamson.co.uk
where you can find information about purchasing castings and see photos of models people have
More information can also be found in the Yahoo Group samson_builders.
A 3D PDF can be down loaded here. Click on the image and then you will be able to rotate/pan/zoom
about the model. Right clicking will allow you hide parts so you can see hidden or internal parts.
The model is not complete yet and will be updated as additions are made.
2D Images in PDF format (The images you can see here are low resolution JPEGs, click on PDF for a better view)
Right Front View
PDF
Left Back View
PDF
Right Back view
PDF
Right view
Left view
PDF
Front view
Back view
